C-SUR – In-Ceiling Speaker

คุณสมบัติสินค้า:

One speaker, multiple applications Like all PSB speakers, the CustomSound C-SUR is prized for its true-to-nature sound. It is also highly versatile, offering several placement options for creating an immersive home theatre experience. Capable of handling 150 watts of amplifier power, the C-SUR is the robust yet discreet in-ceiling speaker your high-end home theatre system deserves. สินค้าราคาต่อตัว

Share

แบรนด์ : PSB

Share

Bring big sound to small rooms
The CustomSound C-SUR in-ceiling speaker uses two 5¼” (133mm) woofers and two 1″ (25mm) tweeters in a unique 5.1/7.1 dual-mode configuration that allows for an unusual installation option. Because each woofer/tweeter pair has its own crossover and input, a single C-SUR can be used for both the surround and surround-back channels, providing an ideal solution for a 7.1 theatre in smaller rooms.

Create the ideal soundstage
The CustomSound C-SUR is also an excellent height-channel speaker because of its diffuse soundfield. This speaker helps pull the sound “off the walls” to create a truly immersive experience. Combine the C-SUR with other speakers in the CustomSound line, such as the C-LCR and W-LCR2, to create a superb home theatre surround sound system.

Designed for acoustic integrity
Housed inside a meticulously engineered enclosure that ensures the acoustic integrity of the design in any installation, the CustomSound C-SUR is uncompromising in its performance, both visually and sonically. As an added benefit, the enclosure reduces sound transmission into adjoining rooms. This is the concealed-speaker system your home is waiting for.

สนใจงานระบบ ติดต่อสอบถามเพิ่มเติม คุณวีระพงศ์ 065-549-9697  ,คุณจิระภากร 092-565-9090

Email : multiroom@conice.co.th

Frequency Response
On Axis @ 0° ±3dB
70-23,000Hz
On Axis @ 0° ±1 1/2dB
75-20,000Hz
LF Cutoff -10dB
65Hz
Sensitivity
Anechoic Chamber
89dB
Listening Room
91dB
Impedance
Nominal
6 Ohms
Minimum
4 Ohms
Input Power
Recommended
20 - 150 Watts
Program
150 Watts
Acoustic Design
Tweeter (Nominal)
2 x 1” (25mm) Titanium Dome with Ferrofluid
Woofer (Nominal)
2 x 5 1/4” (133mm) Clay/Ceramic reinforced Polypropylene Cone

Rubber Surround
Crossover
1500Hz, LR4
Internal Volume
0.4 cu ft (11.2L)
Design Type
Sealed
Dimensions / Weights / Finish
Size (W x H x D)
Cutout Dimensions - 13 3/16 x 13 3/16” * (335 x 335mm)

Mounting Depth - 7 3/4” * (196mm) *

Grille Dimensions - 14 3/4 x 14 3/4 x 3/8” * (373 x 373 x 7mm)
Weight
Net - 17.6lb (8.8kg)/each

Shipping - 24lb (10.9kg)/each
